2.44046 4-circuit-protection valve, M16 x 1,5, M22 x 1,5, max. 10 bar, Po21: 6.3 bar, Po22: 6.3 bar, Po23: 5.8 bar, Po24: 5.8 bar, Pc21: 4.5 bar, Pc22: 4.5 bar, Pc23: 3.8 bar, Pc24: 3.8 bar

2.44046 4-circuit-protection valve, M16 x 1,5, M22 x 1,5, max. 10 bar, Po21: 6.3 bar, Po22: 6.3 bar, Po23: 5.8 bar, Po24: 5.8 bar, Pc21: 4.5 bar, Pc22: 4.5 bar, Pc23: 3.8 bar, Pc24: 3.8 bar

2.44046 4-circuit-protection valve, M16 x 1,5, M22 x 1,5, max. 10 bar, Po21: 6.3 bar, Po22: 6.3 bar, Po23: 5.8 bar, Po24: 5.8 bar, Pc21: 4.5 bar, Pc22: 4.5 bar, Pc23: 3.8 bar, Pc24: 3.8 bar

رمز المخزون: 2.44046
replaces Knorr: AE4452
vida_boyutu_1 M16 x 1,5
vida_boyutu_2 M22 x 1,5
Operating pressure to [bar] 10.00 bar
Opening pressure (21) [bar] 6.30 bar
Opening pressure (22) [bar] 6.30 bar
Opening pressure (23) [bar] 5.80 bar
Opening pressure (24) [bar] 5.80 bar
Closing pressure (21) [bar] 4.50 bar
Closing pressure (22) [bar] 4.50 bar
Closing pressure (23) [bar] 3.80 bar
Closing pressure (24) [bar] 3.80 bar
الوزن 797.00 g
مدة ضمانة 2
ماركة نموذج
Volvo B12M 2001-2011 2001 - 2011 - B12
FM7 1998-2001 1998 - 2001 - FM
ماركة رقم المرجع
Knorr AE4452
Volvo 1075765
